Q600 Unit with 10-port Manifolds

Brand: Zehnder
Product Code: (9320, 9592, 9324)x2, 9615
Dimensions: 36.00in x 23.00in x 54.00in

Price: $6,061.00

Available Options

* Add a Pre-Heater:

The pre-heater is built into the unit and prevents frost in the core during extreme low temperatures. When an earth tube or ground loop is incorporated, the pre-heater may not be needed in the Rocky Mountain regions. Otherwise, most units should add this option.

* Add a set of Controls:
* Use an HRV core:

Most systems in our regional climates prefer an ERV core retaining interior humidity and rejecting summer humidity. You may want to consider an HRV core if you have high interior humidity in your home from indoor pools or hot tubs, solar green rooms, or excessive cooking, etc.

- +

The choice for large residential and small commercial projects or schools, the CA Q600 has a maximum capacity of 354 cfm.

The CA Q600 has all the features of the original ComfoAir series with advanced control system technology and more efficiency in the heat transfer core. Additional options and accessories are also available, like the recommended .

The CA Q600 is a Certified Passive House Component.


  • Comfort Ventilation up to 354 cfm
  • Heat recovery efficiency up to 96%
  • Advanced connectivity and control options, including smart phone app
  • LowPressure monitoring to maintain commissioned flow rates (Self Balancing)
  • Low power consumption thanks to EC direct current motors
  • Automatic summer bypass
  • Frost Protection Function
  • Quick and safe installation, maintenance and servicing
  • Moisture recovery with the Zehnder enthalpy exchanger
  • Simple operation
  • Optional integrated preheater
  • Filter replacement indicator
  • Passivhaus Institut accredited

Dimensions: Height: 33.5”

                        Width: 28.5”

                        Depth: 22.5”

Weight: 110 pounds

Compact sound-absorbing manifold box with closed-cell, silencer inner lining, fits mounting plate for ComfoTube 6 x 3" (75) ventilation pipes and end plate with 7" connection for ComfoPipe.

Includes two ComfoWell 10-port manifolds with 7" ComfoPipe connections for a 10-port distribution system.

Material: Galvanized Steel

Dimensions (each):
Length: 9.0"
Width: 13.8"
Height: 20.0"
